o6 Nodeset Compiler Collection¶
ncc turns OPC UA NodeSet XML into C or Python source code for your application.
OPC UA (Open Platform Communications Unified Architecture) models describe the
types, objects and relationships exposed by a server.
Install the compiler with Python 3.10 or newer:
The installation includes all compiler dependencies. Python generation, including models with initial values, works without o6 installed. Running the generated Python packages requires a compatible o6\Python runtime.
Choose a backend to generate code for your application:
| Backend | Output | Start here |
|---|---|---|
| open62541 | Source and header files that populate an open62541 server. | open62541 quickstart |
| o6\Python | A package that declares and registers a namespace for the o6\Python runtime. | o6\Python quickstart |
Compiler installation and application runtime requirements are separate; check compatibility before choosing a runtime build.
Features¶
| Task | Learn more |
|---|---|
| Generate C structures and datatype tables | Datatype generation |
| Use bundled companion specs offline | Dependencies and bundled companion specs |
| Place custom dependencies in your Python project | Custom dependency locations |
| Inspect a model before generating C or Python code | Inventory |
| Visualize a model's nodes and relationships | Graphviz |
| Use generated Python types and ship the package | Generated packages |
| Complete commands, options and dependency names in your shell | Shell completion |
See the open62541 reference or o6\Python reference
for command syntax and options. cncc and pyncc are aliases for ncc c and
ncc python.
